● The machine is classical model which widely used worldwide over 10years,applying to various sizes of rigid boxes with durable machine life;
● It is PLC system,servo system and pneumatic system controlled;
● The machine equipped with the brand components such as Schneider,CHINT,Panasonic,DELTA,AirTac,SWC and HIWIN;
● The machine equipped with Panasonic Safety-device to ensure safety for machine users.
Email:admin@amamachine.com
Whatsapp:+86 17758110836
Rigid-boxes Display
Main Technical Parameters：
|
MODEL |
AM-A4030 |
AM-A5040 |
AM-A6050 |
|
Max.Size of Box (L×W×H) |
400×300×100mm |
500×400×150mm |
600×500×180mm |
|
Min.Size of Box (L×W×H) |
40×40×10mm |
80×60×10mm |
100×80×15mm |
|
Max.Turn-in Depth |
80mm |
80mm |
90mm |
|
Box Wrapping Speed |
10-20pcs/min |
10-20pcs/min |
10-20pcs/min |
|
Power |
3KW |
3KW |
4KW |
|
Air supply |
≧0.6Mpa |
≧0.6Mpa |
≧0.6Mpa |
|
Voltage |
AC220V,50Hz |
AC220V,50Hz |
AC220V,50Hz |
|
Overall Dimension(L×W×H) |
1100×800×2100mm |
1300×1000×2300mm |
1300×1500×2300mm |
|
Net Weight |
600kgs |
800kgs |
950kgs |
Remark:The certain box-sizes not within the range above and the certain irregular boxes,the machine able to be customized.
