● Rear-suction paper feeding system make paper feeding more stable and avoiding double-sheet feeding;
● PLC system with Touch screen controlling,easier for machine debugging;
● Recycled Gluing sink with Indirect electric-heating and Temperature controlling system to ensure glue in proper viscosity,adjustable Gluing roller ensures even gluing;
● Single-row/Dual-row paper feeding structure and 24-h pre-heating setter to improve efficiency of production;
● Recycled machine cleaning system is convenient for machine users;
● Vaccum-Fan blowing system of Conveyor keeps paper sheet being delivered flat and stably.
Email:admin@amamachine.com
Whatsapp:+86 17758110836
Main Technical Parameters：
|
MODEL |
AM-GS650 |
AM-GS850 |
AM-GS1050 |
|
Feeding Width of paper |
80mm-600mm |
80mm-800mm |
100mm-1000mm |
|
Feeding length of paper |
165mm-1000mm |
165mm-1000mm |
165mm-1000mm |
|
Thickness of paper |
100gsm-230gsm |
100gsm-230gsm |
100gsm-230gsm |
|
Gluing Speed |
10-40pcs/min |
10-40pcs/min |
10-40pcs/min |
|
Layout Dimension (L×W×H) |
(7500x 1600x1300)mm |
(7500x1800x1300)mm |
(7500x2000x1300)mm |
|
Conveyor size(L×W) |
6000mmx600mm |
6000mmx800mm |
6000mmx1000mm |
|
Net Weight |
1050kg |
1100kgs |
1300kgs |
|
Voltage Supply |
AC380V,50HZ |
AC380V,50HZ |
AC380V,50HZ |
